Nextcloud 21 mit Apache2 (http/2) und PHP-FPM (fast track)

Nextcloud 21 mit Apache2
sudo -s

Systemvoraussetzungen

add-apt-repository universe && apt update && apt upgrade -y
apt install -y software-properties-common curl gnupg2 git lsb-release ssl-cert ca-certificates apt-transport-https tree locate software-properties-common dirmngr screen htop net-tools zip unzip bzip2 ffmpeg ghostscript libfile-fcntllock-perl libfontconfig1 libfuse2 socat wget
add-apt-repository -y ppa:ondrej/php && add-apt-repository -y ppa:ondrej/apache2
apt update && apt upgrade -y && apt autoremove -y && apt autoclean -y

Notwendige Verzeichnisse anlegen (Annahme: /var/nc_data wird das Nextcloud-Datenverzeichnis):

mkdir -p /var/www /var/nc_data
chown -R www-data:www-data /var/nc_data /var/www

Installation der Datenbank MariaDB

apt-key adv --recv-keys --keyserver hkps://keyserver.ubuntu.com:443 0xF1656F24C74CD1D8
add-apt-repository 'deb [arch=amd64] http://ftp.hosteurope.de/mirror/mariadb.org/repo/10.5/ubuntu focal main'
apt update && apt install -y mariadb-server

Härtung der MariaDB-Datenbank

mysql_secure_installation

Konfiguration der MariaDB-Datenbank

service mariadb stop && mv /etc/mysql/my.cnf /etc/mysql/my.cnf.bak && nano /etc/mysql/my.cnf

Tragen Sie alle Zeilen in die leere Datei ein:

[client]
default-character-set = utf8mb4
port = 3306
socket = /var/run/mysqld/mysqld.sock
[mysqld_safe]
log_error=/var/log/mysql/mysql_error.log
nice = 0
socket = /var/run/mysqld/mysqld.sock
[mysqld]
basedir = /usr
bind-address = 127.0.0.1
binlog_format = ROW
bulk_insert_buffer_size = 16M
character-set-server = utf8mb4
collation-server = utf8mb4_general_ci
concurrent_insert = 2
connect_timeout = 5
datadir = /var/lib/mysql
default_storage_engine = InnoDB
expire_logs_days = 2
general_log_file = /var/log/mysql/mysql.log
general_log = 0
innodb_buffer_pool_size = 1024M
innodb_buffer_pool_instances = 1
innodb_flush_log_at_trx_commit = 2
innodb_log_buffer_size = 32M
innodb_max_dirty_pages_pct = 90
innodb_file_per_table = 1
innodb_open_files = 400
innodb_io_capacity = 4000
innodb_flush_method = O_DIRECT
key_buffer_size = 128M
lc_messages_dir = /usr/share/mysql
lc_messages = en_US
log_bin = /var/log/mysql/mariadb-bin
log_bin_index = /var/log/mysql/mariadb-bin.index
log_error = /var/log/mysql/mysql_error.log
log_slow_verbosity = query_plan
log_warnings = 2
long_query_time = 1
max_allowed_packet = 16M
max_binlog_size = 100M
max_connections = 200
max_heap_table_size = 64M
myisam_recover_options = BACKUP
myisam_sort_buffer_size = 512M
port = 3306
pid-file = /var/run/mysqld/mysqld.pid
query_cache_limit = 2M
query_cache_size = 64M
query_cache_type = 1
query_cache_min_res_unit = 2k
read_buffer_size = 2M
read_rnd_buffer_size = 1M
skip-external-locking
skip-name-resolve
slow_query_log_file = /var/log/mysql/mariadb-slow.log
slow-query-log = 1
socket = /var/run/mysqld/mysqld.sock
sort_buffer_size = 4M
table_open_cache = 400
thread_cache_size = 128
tmp_table_size = 64M
tmpdir = /tmp
transaction_isolation = READ-COMMITTED
#unix_socket=OFF
user = mysql
wait_timeout = 600
[mysqldump]
max_allowed_packet = 16M
quick
quote-names
[isamchk]
key_buffer = 16M

Neustart der MariaDB-Datenbank und Anlegen der Nextcloud Datenbank sowie des Benutzers:

service mariadb restart
mysql -uroot -p -e "CREATE DATABASE nextcloud CHARACTER SET utf8mb4 COLLATE utf8mb4_general_ci; CREATE USER nextcloud@localhost identified by 'nextcloud'; GRANT ALL PRIVILEGES on nextcloud.* to nextcloud@localhost; FLUSH privileges;"

Installation PHP 7.4

Hinweis: Möchten Sie PHP 8.x verwenden, so ersetzen Sie einfach nachfolgend php7.4 durch php8.0

apt update && apt install -y libapache2-mod-php7.4 php7.4-fpm php7.4-gd php7.4-mysql php7.4-curl php7.4-xml php7.4-zip php7.4-intl php7.4-mbstring php7.4-bz2 php7.4-ldap php7.4-apcu php7.4-bcmath php7.4-gmp php7.4-imagick php7.4-igbinary php7.4-redis php7.4-smbclient php7.4-cli php7.4-common php7.4-opcache php7.4-readline imagemagick php7.4-imagick php7.4-smbclient redis-server php7.4-redis unzip

Setzen Sie das richtige Datumsformat (exemplarisch Europa/Berlin)

timedatectl set-timezone Europe/Berlin

Bevor wir mit den Optimierungen von PHP beginnen sichern wir die Konfigurationsdateien:

cp /etc/php/7.4/fpm/pool.d/www.conf /etc/php/7.4/fpm/pool.d/www.conf.bak
cp /etc/php/7.4/fpm/php-fpm.conf /etc/php/7.4/fpm/php-fpm.conf.bak
cp /etc/php/7.4/cli/php.ini /etc/php/7.4/cli/php.ini.bak
cp /etc/php/7.4/fpm/php.ini /etc/php/7.4/fpm/php.ini.bak
cp /etc/php/7.4/fpm/php-fpm.conf /etc/php/7.4/fpm/php-fpm.conf.bak
cp /etc/php/7.4/mods-available/apcu.ini /etc/php/7.4/mods-available/apcu.ini.bak
cp /etc/ImageMagick-6/policy.xml /etc/ImageMagick-6/policy.xml.bak

Führen Sie nun alle nachfolgenden Optimierungen durch:

sed -i "s/;env\[HOSTNAME\] = /env[HOSTNAME] = /" /etc/php/7.4/fpm/pool.d/www.conf
sed -i "s/;env\[TMP\] = /env[TMP] = /" /etc/php/7.4/fpm/pool.d/www.conf
sed -i "s/;env\[TMPDIR\] = /env[TMPDIR] = /" /etc/php/7.4/fpm/pool.d/www.conf
sed -i "s/;env\[TEMP\] = /env[TEMP] = /" /etc/php/7.4/fpm/pool.d/www.conf
sed -i "s/;env\[PATH\] = /env[PATH] = /" /etc/php/7.4/fpm/pool.d/www.conf
sed -i "s/pm.max_children =.*/pm.max_children = 240/" /etc/php/7.4/fpm/pool.d/www.conf
sed -i "s/pm.start_servers =.*/pm.start_servers = 30/" /etc/php/7.4/fpm/pool.d/www.conf
sed -i "s/pm.min_spare_servers =.*/pm.min_spare_servers = 10/" /etc/php/7.4/fpm/pool.d/www.conf
sed -i "s/pm.max_spare_servers =.*/pm.max_spare_servers = 200/" /etc/php/7.4/fpm/pool.d/www.conf
sed -i "s/;pm.max_requests =.*/pm.max_requests = 1000/" /etc/php/7.4/fpm/pool.d/www.conf
sed -i "s/allow_url_fopen =.*/allow_url_fopen = 1/" /etc/php/7.4/fpm/php.ini
sed -i "s/output_buffering =.*/output_buffering = 'Off'/" /etc/php/7.4/cli/php.ini
sed -i "s/max_execution_time =.*/max_execution_time = 3600/" /etc/php/7.4/cli/php.ini
sed -i "s/max_input_time =.*/max_input_time = 3600/" /etc/php/7.4/cli/php.ini
sed -i "s/post_max_size =.*/post_max_size = 10240M/" /etc/php/7.4/cli/php.ini
sed -i "s/upload_max_filesize =.*/upload_max_filesize = 10240M/" /etc/php/7.4/cli/php.ini
sed -i "s/;date.timezone.*/date.timezone = Europe\/\Berlin/" /etc/php/7.4/cli/php.ini
sed -i "s/memory_limit = 128M/memory_limit = 2048M/" /etc/php/7.4/fpm/php.ini
sed -i "s/output_buffering =.*/output_buffering = 'Off'/" /etc/php/7.4/fpm/php.ini
sed -i "s/max_execution_time =.*/max_execution_time = 3600/" /etc/php/7.4/fpm/php.ini
sed -i "s/max_input_time =.*/max_input_time = 3600/" /etc/php/7.4/fpm/php.ini
sed -i "s/post_max_size =.*/post_max_size = 10240M/" /etc/php/7.4/fpm/php.ini
sed -i "s/upload_max_filesize =.*/upload_max_filesize = 10240M/" /etc/php/7.4/fpm/php.ini
sed -i "s/;date.timezone.*/date.timezone = Europe\/\Berlin/" /etc/php/7.4/fpm/php.ini
sed -i "s/;session.cookie_secure.*/session.cookie_secure = True/" /etc/php/7.4/fpm/php.ini
sed -i "s/;opcache.enable=.*/opcache.enable=1/" /etc/php/7.4/fpm/php.ini
sed -i "s/;opcache.enable_cli=.*/opcache.enable_cli=1/" /etc/php/7.4/fpm/php.ini
sed -i "s/;opcache.memory_consumption=.*/opcache.memory_consumption=128/" /etc/php/7.4/fpm/php.ini
sed -i "s/;opcache.interned_strings_buffer=.*/opcache.interned_strings_buffer=8/" /etc/php/7.4/fpm/php.ini
sed -i "s/;opcache.max_accelerated_files=.*/opcache.max_accelerated_files=10000/" /etc/php/7.4/fpm/php.ini
sed -i "s/;opcache.revalidate_freq=.*/opcache.revalidate_freq=1/" /etc/php/7.4/fpm/php.ini
sed -i "s/;opcache.save_comments=.*/opcache.save_comments=1/" /etc/php/7.4/fpm/php.ini
sed -i "s|;emergency_restart_threshold.*|emergency_restart_threshold = 10|g" /etc/php/7.4/fpm/php-fpm.conf
sed -i "s|;emergency_restart_interval.*|emergency_restart_interval = 1m|g" /etc/php/7.4/fpm/php-fpm.conf
sed -i "s|;process_control_timeout.*|process_control_timeout = 10|g" /etc/php/7.4/fpm/php-fpm.conf
sed -i '$aapc.enable_cli=1' /etc/php/7.4/mods-available/apcu.ini
sed -i "s/rights=\"none\" pattern=\"PS\"/rights=\"read|write\" pattern=\"PS\"/" /etc/ImageMagick-6/policy.xml
sed -i "s/rights=\"none\" pattern=\"EPS\"/rights=\"read|write\" pattern=\"EPS\"/" /etc/ImageMagick-6/policy.xml
sed -i "s/rights=\"none\" pattern=\"PDF\"/rights=\"read|write\" pattern=\"PDF\"/" /etc/ImageMagick-6/policy.xml
sed -i "s/rights=\"none\" pattern=\"XPS\"/rights=\"read|write\" pattern=\"XPS\"/" /etc/ImageMagick-6/policy.xml

Starten Sie nun die Dienste neu

service php7.4-fpm restart
a2dismod php7.4 && a2dismod mpm_prefork
a2enmod proxy_fcgi setenvif mpm_event http2
service apache2 restart
a2enconf php7.4-fpm
service apache2 restart && service php7.4-fpm restart

Download Nextcloud latest

wget https://download.nextcloud.com/server/releases/latest.zip
unzip latest.zip && mv nextcloud/ /var/www/html/ && chown -R www-data:www-data /var/www/html/nextcloud && rm -f latest.zip

Anpassungen Redis

cp /etc/redis/redis.conf /etc/redis/redis.conf.bak
sed -i "s/port 6379/port 0/" /etc/redis/redis.conf
sed -i s/\#\ unixsocket/\unixsocket/g /etc/redis/redis.conf
sed -i "s/unixsocketperm 700/unixsocketperm 770/" /etc/redis/redis.conf
sed -i "s/# maxclients 10000/maxclients 512/" /etc/redis/redis.conf
usermod -aG redis www-data
cp /etc/sysctl.conf /etc/sysctl.conf.bak
sed -i '$avm.overcommit_memory = 1' /etc/sysctl.conf
reboot now

Apache2 anpassen

a2enmod rewrite headers env dir mime
nano /etc/apache2/mods-available/http2.conf
# mod_http2 doesn't work with mpm_prefork
<IfModule !mpm_prefork>
Protocols h2 h2c http/1.1
H2Direct on
H2StreamMaxMemSize 5120000000
[...]
service apache2 restart
cp /etc/apache2/sites-available/000-default.conf /etc/apache2/sites-available/001-nextcloud.conf
a2dissite 000-default.conf
nano /etc/apache2/sites-available/001-nextcloud.conf

Passen Sie die Datei und insbesondere die roten Werte an Ihr System an

<VirtualHost *:80>
ServerName ihre.domain.de
ServerAlias ihre.domain.de
ServerAdmin mail@domain.de
DocumentRoot /var/www/html/nextcloud
ErrorLog /var/log/apache2/error.log
CustomLog /var/log/apache2/access.log combined
RewriteEngine on
RewriteCond %{SERVER_NAME} =ihre.domain.de
RewriteRule ^ https://%{SERVER_NAME}%{REQUEST_URI} [END,NE,R=permanent]
</VirtualHost>
nano /etc/apache2/sites-available/001-nextcloud-le-ssl.conf

Übernehmen Sie alle Zeilen und passen die roten Werte an Ihr System an

<IfModule mod_ssl.c>
SSLUseStapling on
SSLStaplingCache shmcb:/var/run/ocsp(128000)
<VirtualHost *:443>
SSLCertificateFile /etc/ssl/certs/ssl-cert-snakeoil.pem
SSLCACertificateFile /etc/ssl/certs/ssl-cert-snakeoil.pem
SSLCertificateKeyFile /etc/ssl/private/ssl-cert-snakeoil.key
Protocols h2 h2c http/1.1
Header add Strict-Transport-Security: "max-age=15552000;includeSubdomains"
ServerAdmin mail@domain.de
ServerName ihre.domain.de
ServerAlias ihre.domain.de
SSLEngine on
SSLCompression off
SSLOptions +StrictRequire
SSLProtocol -all +TLSv1.3 +TLSv1.2
SSLCipherSuite ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES128-GCM-SHA256:ECDHE-ECDSA-AES256-GCM-SHA384:ECDHE-RSA-AES256-GCM-SHA384:ECDHE-ECDSA-CHACHA20-POLY1305:ECDHE-RSA-CHACHA20-POLY1305:DHE-RSA-AES128-GCM-SHA256:DHE-RSA-AES256-GCM-SHA384
SSLHonorCipherOrder off
SSLSessionTickets off
ServerSignature off
SSLStaplingResponderTimeout 5
SSLStaplingReturnResponderErrors off
SSLOpenSSLConfCmd Curves X448:secp521r1:secp384r1:prime256v1
SSLOpenSSLConfCmd ECDHParameters secp384r1
SSLOpenSSLConfCmd DHParameters "/etc/ssl/certs/dhparam.pem"
LogLevel warn
CustomLog /var/log/apache2/access.log combined
ErrorLog /var/log/apache2/error.log
DocumentRoot /var/www/html/nextcloud
<Directory /var/www/html/nextcloud/>
Options Indexes FollowSymLinks
AllowOverride All
Require all granted
Satisfy Any
</Directory>
<IfModule mod_dav.c>
Dav off
</IfModule>
<Directory /var/nc_data/>
Require all denied
</Directory>
<Files ".ht*">
Require all denied
</Files>
TraceEnable off
RewriteEngine On
RewriteCond %{REQUEST_METHOD} ^TRACK
RewriteRule .* - [R=405,L]
SetEnv HOME /var/www/html/nextcloud
SetEnv HTTP_HOME /var/www/html/nextcloud
<IfModule mod_reqtimeout.c>
RequestReadTimeout body=0
</IfModule>
</VirtualHost>
</IfModule>

Sicherheit erweitern und aktivieren

openssl dhparam -dsaparam -out /etc/ssl/certs/dhparam.pem 4096
nano /etc/apache2/apache2.conf

ServerName ihre.domain.de ganz oben, am Anfang der Datei ergänzen und None durch All ersetzen

ServerName ihre.domain.de
[...]
<Directory /var/www/>
Options Indexes FollowSymLinks
AllowOverride All
Require all granted
</Directory>
service apache2 restart

Installation der Nextcloud

sudo -u www-data php /var/www/html/nextcloud/occ maintenance:install --database "mysql" --database-name "nextcloud" --database-user "nextcloud" --database-pass "nextcloud" --admin-user "Nextcloud-Admin" --admin-pass "Nextcloud-Admin-Passswort" --data-dir "/var/nc_data"

Weitere Anpassungen – bitte alle Zeilen am Ende der Datei hinzufügen

sudo -u www-data nano /var/www/html/nextcloud/.htaccess
[...]
ErrorDocument 403 /
ErrorDocument 404 /
<IfModule mod_rewrite.c>
Options -MultiViews
RewriteRule ^core/js/oc.js$ index.php [PT,E=PATH_INFO:$1]
RewriteRule ^core/preview.png$ index.php [PT,E=PATH_INFO:$1]
RewriteCond %{REQUEST_FILENAME} !\.(css|js|svg|gif|png|html|ttf|woff2?|ico|jpg|jpeg)$
RewriteCond %{REQUEST_FILENAME} !core/img/favicon.ico$
RewriteCond %{REQUEST_FILENAME} !core/img/manifest.json$
RewriteCond %{REQUEST_FILENAME} !/remote.php
RewriteCond %{REQUEST_FILENAME} !/public.php
RewriteCond %{REQUEST_FILENAME} !/cron.php
RewriteCond %{REQUEST_FILENAME} !/core/ajax/update.php
RewriteCond %{REQUEST_FILENAME} !/status.php
RewriteCond %{REQUEST_FILENAME} !/ocs/v1.php
RewriteCond %{REQUEST_FILENAME} !/ocs/v2.php
RewriteCond %{REQUEST_FILENAME} !/robots.txt
RewriteCond %{REQUEST_FILENAME} !/updater/
RewriteCond %{REQUEST_FILENAME} !/ocs-provider/
RewriteCond %{REQUEST_URI} !^/\.well-known/(acme-challenge|pki-validation)/.*
RewriteRule . index.php [PT,E=PATH_INFO:$1]
RewriteBase /
<IfModule mod_env.c>
SetEnv front_controller_active true
<IfModule mod_dir.c>
DirectorySlash off
</IfModule>
</IfModule>
</IfModule>

Nextcloud .htaccess korrigieren

sudo -u www-data php /var/www/html/nextcloud/occ maintenance:update:htaccess

Nextcloud-Anpassungen

sudo -u www-data cp /var/www/html/nextcloud/config/config.php /var/www/html/nextcloud/config/config.php.bak
sudo -u www-data sed -i 's/^[ ]*//' /var/www/html/nextcloud/config/config.php
sudo -u www-data sed -i '/);/d' /var/www/html/nextcloud/config/config.php
sudo -u www-data cat <<EOF >>/var/www/html/nextcloud/config/config.php
'activity_expire_days' => 14,
'auth.bruteforce.protection.enabled' => true,
'blacklisted_files' =>
array (
0 => '.htaccess',
1 => 'Thumbs.db',
2 => 'thumbs.db',
),
'cron_log' => true,
'default_phone_region' => 'DE',
'enable_previews' => true,
'enabledPreviewProviders' =>
array (
0 => 'OC\\Preview\\PNG',
1 => 'OC\\Preview\\JPEG',
2 => 'OC\\Preview\\GIF',
3 => 'OC\\Preview\\BMP',
4 => 'OC\\Preview\\XBitmap',
5 => 'OC\\Preview\\Movie',
6 => 'OC\\Preview\\PDF',
7 => 'OC\\Preview\\MP3',
8 => 'OC\\Preview\\TXT',
9 => 'OC\\Preview\\MarkDown',
),
'filesystem_check_changes' => 0,
'filelocking.enabled' => 'true',
'htaccess.RewriteBase' => '/',
'integrity.check.disabled' => false,
'knowledgebaseenabled' => false,
'logfile' => '/var/nc_data/nextcloud.log',
'logtimezone' => 'Europe/Berlin',
'log_rotate_size' => 104857600,
'maintenance' => false,
'memcache.local' => '\\OC\\Memcache\\APCu',
'memcache.locking' => '\\OC\\Memcache\\Redis',
'overwriteprotocol' => 'https',
'preview_max_x' => 1024,
'preview_max_y' => 768,
'preview_max_scale_factor' => 1,
'redis' =>
array (
'host' => '/var/run/redis/redis-server.sock',
'port' => 0,
'timeout' => 0.0,
),
'quota_include_external_storage' => false,
'share_folder' => '/Freigaben',
'skeletondirectory' => '',
'theme' => '',
'trashbin_retention_obligation' => 'auto, 14',
'updater.release.channel' => 'stable',
);
EOF
sudo -u www-data php /var/www/html/nextcloud occ config:system:set remember_login_cookie_lifetime --value="1800"
sudo -u www-data php /var/www/html/nextcloud occ config:system:set simpleSignUpLink.shown --type=bool --value=false
sudo -u www-data php /var/www/html/nextcloud occ config:system:set versions_retention_obligation --value="auto, 365"
sudo -u www-data php /var/www/html/nextcloud occ config:system:set loglevel --value=2
sudo -u www-data php /var/www/html/nextcloud/occ config:system:set trusted_domains 1 --value=ihre.domain.de
a2enmod ssl && a2ensite 001-nextcloud.conf 001-nextcloud-le-ssl.conf
service php7.4-fpm restart && service redis-server restart && service apache2 restart

Cronjob

crontab -u www-data -e

Fügen Sie am Ende diese Zeile hinzu

*/5 * * * * php -f /var/www/nextcloud/cron.php > /dev/null 2>&1

Aktivieren Sie den Cronjob innerhalb der Nextcloud

sudo -u www-data php /var/www/html/nextcloud/occ background:cron

Weitere Härtungen

a2dismod status
nano /etc/apache2/conf-available/security.conf
[...]
ServerTokens Prod
[...]
ServerSignature Off
[...]
TraceEnable Off
[...]
service php7.4-fpm restart && service redis-server restart && service apache2 restart

Installieren Sie fail2ban

apt install -y fail2ban ufw
touch /etc/fail2ban/filter.d/nextcloud.conf
cat <<EOF >/etc/fail2ban/filter.d/nextcloud.conf
[Definition]
_groupsre = (?:(?:,?\s*"\w+":(?:"[^"]+"|\w+))*)
failregex = ^\{%(_groupsre)s,?\s*"remoteAddr":"<HOST>"%(_groupsre)s,?\s*"message":"Login failed:
            ^\{%(_groupsre)s,?\s*"remoteAddr":"<HOST>"%(_groupsre)s,?\s*"message":"Trusted domain error.
datepattern = ,?\s*"time"\s*:\s*"%%Y-%%m-%%d[T ]%%H:%%M:%%S(%%z)?"
EOF

Legen Sie nun eine neue Jail-Datei an

nano /etc/fail2ban/jail.d/nextcloud.local

Kopieren Sie alle nachfolgenden Zeilen hinein:

[nextcloud]
backend = auto
enabled = true
port = 80,443
protocol = tcp
filter = nextcloud
maxretry = 5
bantime = 3600
findtime = 36000
logpath = /var/nc_data/nextcloud.log
service fail2ban restart

Aktivieren Sie die Firewall und passen Sie den SSH-Port 22 ggf. an

ufw allow 80/tcp && ufw allow 443/tcp && ufw allow 22/tcp
ufw logging medium
ufw enable
service ufw restart

© Carsten Rieger IT-Services
